FDY premium quality · 0AM DQ200

Mechatronic Overhaul
Repair Kit

A comprehensive repair kit for the Audi, VW, Škoda and Seat 7-speed DSG with the 0AM (DQ200) dry dual-clutch system. All the seals, gaskets and the oil filter you need to restore the mechatronic / hydraulic unit.

15 components
Audi · VW · Škoda · Seat
Oil filter included

Get a quote WhatsApp

What's in the box

Kit contents

Every component needed for a complete mechatronic overhaul, packed as one kit — no hunting for individual seals.

Item	Qty
Metal plate / housing	1×
O-ring for hydraulic pressure sensor	1×
Sub-kit for clutch actuator seals	1×
Sub-kit for gear selector bellows, seals and O-rings	1×
Sub-kit for rubber gaskets on electric plate	1×
Sub-kit with check balls	1×
Sub-kit with seal washers (aluminium and copper)	1×
Sub-kit for hydraulic pump seals	1×
Sub-kit for solenoid O-rings	1×
Cover gasket	1×
Metal separator plate gasket	1×
Metal gaskets for solenoid connectors	2×
Outer O-ring for pressure accumulator	1×
Oil filter	1×
Breather cap	1×

Reference part numbers

Replacement for VW, Audi, Škoda and Seat

DQ200 0AM DSG 7-speed gearbox transmission mechatronic overhaul repair gasket & seal kit. Click a code to copy it.

Includes valve body & accumulator housing

Part numbers 0AM325066AC and 0AM325066C.

Fitment

Fits the following vehicles

All listed applications are 7-speed, front-wheel drive (FWD). Not sure about your vehicle? Send us the VIN and we'll confirm.

Volkswagen

13 MODELS

Model	Years	Engines
Beetle	2011–on	1.4L / 1.6L / 1.8L
Bora	2010–2011	1.6L
Caddy Van	2010–2011	1.4L / 1.6L
Golf / Golf Plus	2007–2010	1.4L / 1.6L / 1.9L / 2.5L
Jetta Wagon	2008–2011	2.0L
Lavida	2010–2011	1.4L / 1.6L
Passat	2008–2011	1.4L / 1.8L
Polo	2007–2010	1.2L / 1.4L
Sagitar	2009–2011	1.4L
Scirocco	2009–2011	1.4L
Sharan	2010–2011	1.4L
Tiguan	2011–on	1.4L / 1.8L
Touran	2010–2011	1.4L / 1.6L / 1.8L
